The equipment parameter:
equipment size: 1600mm*1100mm*1600mm(length * width * height)
Weight: about 200kg
Voltage: AC220V / 2 kw
Pull shaft: mechanical bias type
Transmission motor: servomotor
Maximum label diameter: 400mm
Maximum tag width: 150mm
Winding tension: automatic tension adjustment
Operating mode: step and continuous
Suitable material: rolled electronic label (adhesive label, Inlay label)
Running speed :(0-50 m)/min
Software functional parameters:
Detection system: SAIYU system
Testing function: check whether the label chip is qualified. If not, the code printer is not working
Parameters of UV printer:
Sprinkler head: ricoh G5
Maximum size: 54mm in width
Ink supply system: central ink supply system
Resolution: 600/dpi
Interface: serial port, Ethernet port, electric eye, encoder interface, print sprinkler interface
Sensors: support a variety of external sensors (NPN type, contact type)
Operating system: Windows7
Object: dynamic text, counter, date, dynamic bar code, static text, picture (dynamic)
Bar code type: 1d code (EAN28, Code25, Code39, Code93, Code128, GS1Databar)
QR Code (PDF417, DataMatrix, Maxi Code, QR Code)
The feeding accuracy: 0.25mm Max
